Generate Synthetic Data¶

Synthetic Data Generation (SDG) Methods¶

Our study leverages five synthetic data generation (SDG) methods through their official libraries.

Avatars

CTGAN

Gaussian Copula

Synthpop

TVAE

Five SDG methods were benchmarked across three cancer types (NSCLC, melanoma, ccRCC), each repeated 5 times with different random seeds to assess the robustness of each method.

Naive fitting of synthetic data generation methods often fails on high-dimensional and heterogeneous multi-omic datasets. Therefore, we designed adaptations for each method to handle these challenges.

CTGAN and TVAE requires GPU for training on high-dimensional data.
Gaussian Copula requires a suitable encoding for categorical variables.
Synthpop requires a custom predictor matrix optimization to handle high-dimensional data.
Avatars requires a feature clustering to partition the features into batch before submitting to the API.

Detail description of each adaptation is provided in the manuscript of this work and GitHub repository.

Usage Example¶

1. Gaussian Copula¶

from synomicsbench.synthesizer.GaussianCopulasynthesizer import GaussianCopulasynthesizer
from synomicsbench.processing.metadata import MetaData

original_data = pd.read_csv("original_data.csv")
metadata = MetaData.get_metadata(
    data=original_data,
    ordinal_features= [] #your ordinal feature list,
    threshold_unique_values = 10
)

seed = 42

output_path = "gaussiancopula_result"
synth = GaussianCopulasynthesizer(output_path=output_path, metadata=metadata)

synthetic_data = synth.generate(
data=original_data,
n_samples=original_data.shape[0],
seed=seed,
fit_params={"n_jobs": -1, "chunk_size": 1000},
output_filename="gaussiancopula_synthetic_data.csv",
)

2. CTGAN¶

import pandas as pd
from synomicsbench.synthesizer.CTGANsynthesizer import CTGANsynthesizer

synthesizer = CTGANsynthesizer(output_path=f"ctgan_result", metadata=metadata)
synthetic_data = synthesizer.generate(
    data=original_data,
    n_samples=original_data.shape[0],
    seed=4,
    fit_params={"epochs": 200, "verbose": False, "cuda": True},
    output_filename="synthetic_data_ctgan.csv"
)

3. TVAE¶

import pandas as pd
from synomicsbench.synthesizer.TVAEsynthesizer import TVAEsynthesizer

synthesizer = TVAEsynthesizer(output_path=f"tvae_result", metadata=metadata)

synthetic_data = synthesizer.generate(
    data=original_data,
    n_samples=original_data.shape[0],
    seed=42,
    fit_params={"epochs": 500, "verbose": False, "cuda": True},
    output_filename="synthetic_data_tvae.csv"
)

4. Synthpop¶

[!NOTE] Synthpop requires R installation. You can install R from CRAN. If you don't have R, you can try the apptainer image.

import pandas as pd
import numpy as np
from synomicsbench.synthesizer.Synthpopsynthesizer import SynthpopSynthesizer

# Prepare categorical features
grouped_metadata = MetaData.grouping_features_astype(original_data, metadata)
categorical_features = grouped_metadata.get("ordinal_categorical") + \
                       grouped_metadata.get("dummy_categorical") + \


# Load and configure predictor matrix for high-dimensional data
predictor_matrix = np.load("synthpop/predictor_matrix.npy")
predictor_df = pd.DataFrame(predictor_matrix, index=original_data.columns, columns=original_data.columns)

synth = SynthpopSynthesizer(output_path=f"synthpop_result", metadata=metadata)
synthetic_data = synth.generate(
    data=original_data,
    seed=42,
    n_samples=original_data.shape[0],
    sample_params={
        "discrete_columns": categorical_features,
        "method": "cart",
        "predictor_matrix": predictor_df
    },
    output_filename="synthpop_synthetic_data.csv"
)

5. Avatars¶

[!NOTE] Avatars requires a proprietary Octopize license. The example below highlights the specialized adaptations (data block chunking and feature clustering) used in SynOmicsBench to handle high-dimensional omic data over the API.

import pandas as pd
import json
from avatars.manager import Manager
from avatars.models import JobKind

# Authenticate with the Avatars API
manager = Manager(base_url="https://www.octopize.app/api")
manager.authenticate("user@company.com", "password", should_verify_compatibility=False)

# Load clustered features optimized for high-dimensional data
with open("avatars/cluster_final.json", "r") as f:
    cluster_features = json.load(f)

k = 10
seed = 42

# Process data iteratively in partitioned blocks
for i in range(len(cluster_features)):
    data_clean = pd.read_csv(f"avatars/original_blocks/original_block_{i}.csv").drop(columns=["Patient_ID"])

    table_name = f"block_{i}"
    runner = manager.create_runner(f"Job_Block_{i}", seed=seed)
    runner.add_table(table_name, data_clean)
    runner.set_parameters(table_name, k=k)

    # Run the synthesis job
    runner.run(jobs_to_run=[JobKind.standard])

    # Retrieve and save the synthetic data block
    synthetic_df = runner.sensitive_unshuffled(table_name)
    synthetic_df.to_csv(f"synthetic_block_{i}.csv", index=False)

#Once all blocks are generated, concatenate them to form the final synthetic dataset
concat_syns = []

for i in range(0, len(cluster_features)):
    block = pd.read_csv(f"synthetic_block_{i}.csv", index_col =False)
    concat_syns.append(block)

synthetic_data = pd.concat(concat_syns, axis = 1)
